Configuring a Trunk port on a Cisco Switch

Jay

06 Aug 2009 • 2 min read

What is a Trunk Port?

A trunk port is a switch port that can carry traffic from multiple VLANs. Unlike an access port which belongs to only one VLAN, a trunk port uses VLAN tagging to identify which VLAN each frame belongs to as it travels across the trunk link.

When to Use Trunk Ports

Trunk ports are commonly used for:

Connecting switches to other switches
Connecting switches to routers for inter-VLAN routing
Connecting to servers that need access to multiple VLANs

VLAN Tagging Protocols

Cisco switches support two main trunking protocols:

802.1Q (IEEE Standard)

This is the industry standard trunking protocol. It adds a 4-byte tag to Ethernet frames to identify the VLAN. One VLAN (usually VLAN 1) is designated as the "native VLAN" and its frames are not tagged.

ISL (Inter-Switch Link)

This is Cisco's proprietary trunking protocol. It encapsulates the entire Ethernet frame with a 26-byte ISL header. ISL is considered legacy and is rarely used on modern switches.

Configuring a Trunk Port

Here's how to configure a trunk port on a Cisco switch:

Basic Trunk Configuration

Switch(config)# interface gigabitethernet 0/1
Switch(config-if)# switchport mode trunk
Switch(config-if)# switchport trunk encapsulation dot1q

Note: On some newer switches, the switchport trunk encapsulation command is not needed as 802.1Q is the only supported encapsulation.

Specifying Allowed VLANs

By default, a trunk port allows all VLANs (1-4094). You can restrict which VLANs are allowed:

Switch(config-if)# switchport trunk allowed vlan 10,20,30
Switch(config-if)# switchport trunk allowed vlan add 40
Switch(config-if)# switchport trunk allowed vlan remove 20

Setting the Native VLAN

The native VLAN is the VLAN whose frames are not tagged on an 802.1Q trunk. By default, this is VLAN 1:

Switch(config-if)# switchport trunk native vlan 99

Security Best Practice: Change the native VLAN from the default VLAN 1 to an unused VLAN to prevent VLAN hopping attacks.

Verification Commands

Use these commands to verify your trunk configuration:

Switch# show interfaces trunk
Switch# show interfaces gigabitethernet 0/1 switchport
Switch# show vlan brief

Example: Complete Trunk Configuration

Here's a complete example configuring a trunk between two switches:

! Switch 1 Configuration
Switch1(config)# interface gigabitethernet 0/24
Switch1(config-if)# description Trunk to Switch2
Switch1(config-if)# switchport mode trunk
Switch1(config-if)# switchport trunk native vlan 99
Switch1(config-if)# switchport trunk allowed vlan 10,20,30,99
Switch1(config-if)# no shutdown

! Switch 2 Configuration
Switch2(config)# interface gigabitethernet 0/24
Switch2(config-if)# description Trunk to Switch1
Switch2(config-if)# switchport mode trunk
Switch2(config-if)# switchport trunk native vlan 99
Switch2(config-if)# switchport trunk allowed vlan 10,20,30,99
Switch2(config-if)# no shutdown

Troubleshooting Trunk Ports

Common issues with trunk configurations include:

Native VLAN mismatch: Both ends of the trunk must have the same native VLAN
Allowed VLAN mismatch: VLANs must be allowed on both ends of the trunk
Encapsulation mismatch: Both switches must use the same trunking protocol
DTP issues: Dynamic Trunking Protocol can sometimes cause negotiation problems

To disable DTP and force the port into trunk mode:

Switch(config-if)# switchport mode trunk
Switch(config-if)# switchport nonegotiate

Summary

Trunk ports are essential for carrying multiple VLANs across switch links. The key points to remember are:

Use switchport mode trunk to configure a trunk port
802.1Q is the standard trunking protocol
Change the native VLAN from VLAN 1 for security
Ensure both ends of the trunk have matching configuration
Use verification commands to confirm proper operation
