Upgrading the IOS on a Cisco Router

When upgrading the IOS on a Cisco router, it's important to follow proper procedures to avoid damaging the device or causing network downtime. This guide will walk you through the process step by step.

Prerequisites

Before beginning the upgrade process, ensure you have:

• Access to the router's console or Telnet/SSH session
• The correct IOS image file for your router model
• Sufficient flash memory space
• A backup of the current configuration
• A TFTP server (if transferring via network)

Step 1: Check Current IOS Version

First, verify the current IOS version and available flash memory:

Router# show version
Router# show flash

The show version command displays the current IOS version, while show flash shows available flash memory space.

Step 2: Copy the New IOS Image

Transfer the new IOS image to the router's flash memory. You can use TFTP, FTP, or other file transfer methods:

Router# copy tftp flash
Address or name of remote host []? 192.168.1.100
Source filename []? c2900-universalk9-mz.SPA.157-3.M5.bin
Destination filename [c2900-universalk9-mz.SPA.157-3.M5.bin]?
Accessing tftp://192.168.1.100/c2900-universalk9-mz.SPA.157-3.M5.bin...
Loading c2900-universalk9-mz.SPA.157-3.M5.bin from 192.168.1.100:
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
[OK - 71710720 bytes]

71710720 bytes copied in 180.156 secs (398036 bytes/sec)

Step 3: Verify the Image

After copying, verify the integrity of the new IOS image:

Router# verify flash:c2900-universalk9-mz.SPA.157-3.M5.bin

This command checks the MD5 hash of the file to ensure it wasn't corrupted during transfer.

Step 4: Configure Boot System

Set the router to boot from the new IOS image:

Router# configure terminal
Router(config)# boot system flash c2900-universalk9-mz.SPA.157-3.M5.bin
Router(config)# exit
Router# copy running-config startup-config

Step 5: Reload the Router

Reload the router to boot from the new IOS image:

Router# reload

The router will restart and boot from the new IOS version.

Step 6: Verify the Upgrade

After the router boots up, verify that it's running the new IOS version:

Router# show version

Check that the version information reflects the new IOS image.

Troubleshooting

If the router fails to boot with the new IOS:

• Use the boot system command in ROMMON mode to specify the correct image
• Check if there's sufficient memory
• Verify the image file isn't corrupted
• Consider using the old IOS image as a fallback

Best Practices

• Always backup your configuration before upgrading
• Test upgrades in a lab environment first
• Keep the old IOS image as a backup
• Schedule upgrades during maintenance windows
• Have console access available during the upgrade

Following these steps will help ensure a successful IOS upgrade on your Cisco router. Remember to always plan upgrades carefully and have a rollback strategy in case issues arise.
