What is FTP and How is it Used?

When you download a file from a server or upload content to a website, there is a good chance a protocol called FTP is involved somewhere in that process. FTP, or the File Transfer Protocol, is one of the oldest and most widely recognized protocols in networking. For the CCST Networking exam, understanding what FTP is, how it works, and where it fits in the real world is an important foundation to build.

What is FTP?

FTP is a standard network protocol used to transfer files between a client and a server over a TCP/IP network. It was originally defined in RFC 959 and has been in use since the early days of the internet. Despite being old, it remains relevant because so many systems still rely on it for file transfer tasks.

FTP operates on a client-server model. The client initiates a connection to the server, authenticates with a username and password, and then can upload or download files. The server listens for incoming connections and serves the requested files.

How FTP Works: The Two-Channel Model

One thing that makes FTP unique compared to other protocols is that it uses two separate TCP connections to do its job:

• Control Connection (Port 21): This channel stays open for the entire session. It carries commands (like GET, PUT, LIST) and responses between the client and server.
• Data Connection (Port 20 or a dynamic port): This channel is opened only when actual file data or directory listings need to be transferred. It closes again once the transfer is complete.

This two-channel design is why FTP can sometimes cause headaches with firewalls. The firewall needs to allow both connections, and the dynamic data port can be unpredictable depending on whether FTP is running in active or passive mode.

Active vs. Passive Mode

• Active Mode: The server initiates the data connection back to the client. This can be blocked by firewalls protecting the client.
• Passive Mode: The client initiates both connections. This is more firewall-friendly and is the standard for most modern FTP clients.

A Quick FTP Session Example

Here is what a basic FTP session looks like from a Linux or Windows command line:

ftp 192.168.1.100
Connected to 192.168.1.100.
220 FTP Server Ready
Name (192.168.1.100:user): admin
331 Password required for admin.
Password:
230 User admin logged in.
ftp> ls
200 PORT command successful.
150 Opening data connection.
-rw-r--r-- 1 admin admin 2048 Oct 01 10:00 report.txt
226 Transfer complete.
ftp> get report.txt
150 Opening data connection for report.txt.
226 Transfer complete.
ftp> bye
221 Goodbye.

In this example, the ls command lists files on the server, and get downloads a file called report.txt to the local machine. The put command works in reverse, uploading a file to the server.

Common FTP Uses in the Real World

FTP has a wide range of practical applications, even today:

• Web hosting: Developers upload website files to a hosting server using FTP clients like FileZilla.
• Software distribution: Companies host software packages on FTP servers for users to download.
• Network device backups: Cisco routers and switches can save configuration files to an FTP server for safekeeping.
• Automated file transfers: Scripts use FTP to move reports, logs, or data files between systems on a schedule.

A Word on Security

FTP transmits data, including usernames and passwords, in plain text. This means anyone on the network who captures the traffic can read it. For this reason, more secure alternatives are commonly used in production environments:

• SFTP (SSH File Transfer Protocol): Runs over SSH and encrypts the entire session.
• FTPS (FTP Secure): Adds TLS encryption to the traditional FTP protocol.

For the CCST exam, you should know that FTP exists and what it does, but also recognize that it is not considered secure for sensitive data.

What's Next

Now that you understand how FTP works and where it fits in the networking world, the next step is exploring other application-layer protocols that handle communication in different ways. In the next post, we will look at email protocols like SMTP, POP3, and IMAP, and how they work together to deliver messages across the internet. These are closely related to FTP in terms of where they sit in the protocol stack, and understanding them will round out your knowledge of key internet services.
